AWS DMS Replication Configuration

To create Replication instance

Name : Your desired name

Instance Class : Types of instance required

Engine Version : Default

High Availability : Select Multi-AZ or Single AZ

Allocated storage (GiB) : As per requirement

And select your VPC and all

Note once you have created allow public ip or security group in your RDS security group

To Create Source and Target Endpoints

1st Select Source endpoint and provide endpoint name

Now select Source engine and choose your desired engine type

*If your source endpoint is your AWS RDS instance then choose Select RDS DB instance and select your RDS instance

Then select your VPC and Replication instance and click on test connection and if the test is successful then your endpoint is created.*

Access to endpoint database : Choose Provide access information manually

Server name : Your server endpoint

Port : 3306 (your sql tcp port)

User name : db user name

Password : DB password

Do the same process for your target instance and test the connection status

To configure Full DB Replication or 1 table of a database go to Database migration tasks

Create new task

Task identifier = Your Task Name

Migration Type = Migrate Existing Data

Target table preparation = Truncate

LOB column settings = Limited LOB mode

Maximum LOB size (KB) = 6400

If want to enable logs select Turn on CloudWatch Logs

Table Mappings

 Editing mode = Wizard

Select Selection rules and Add new selection rule

Schema = EnterSchema

Source name : Source Database Name

Source table name : % (For all tables)  Or Name of Table of the database

Action : Include

Note : If we want to replicate multiple tables then we have to select Add new selection rule for each table

Now select Transformation rules and Add transformation rule

Rule target : schema

Source name : EnterSchema

Source name : Source Database Name

Action : rename and in blank box type Destination Database

Click on Save and select Manually Start

Then select your migration task

#####=================================#####
